LDV SERIES READY TO MOUNT TURNTABLE BEARING ASSEMBLIES
Steel construction with prepared mounting holes on inner & outer rings, High accuracy & load ratings special constructions & sizes can be provided for series production volumes. ALL SIZES FROM UK STOCK. SOME SIZES WITH CORROTECT ANTI-CORROSIVE FINISH FROM STOCK.
LINEAR GUIDEWAYS Franke FD series Industry standard size linear guideways combine low weight, high speeds & accuracies with minimal maintenance. Sealed needle roller bearings give equal load capacity in all directions & unlike recirculating ball/roller type guides do not need periodic re-grease or oil replenishment. Available from stock in the UK in standard & corrosion free types in all sizes franke linear guides can be supplied in special constructions for Vacuum, High temperature (200 C) non-magnetic, & are approved for class 1000 clean room use as standard. ALL SIZES (15-45) FROM UK STOCK.
|
Franke wire race bearing elements & ballcages enable direct integration of the bearing into your application saving weight, space, & cost. High accuracy & load capacity in all directions is realised within a compact envelope. Various profiles & materials give you the widest choice available for optimum flexibility in your design. Diameters up to 7000mm can be realised.
Franke bearing assemblies offer ready to mount solutions in steel & aluminium with or without internal/external gears in diameters up to 1500mm LDV Turntable bearings are available from UK stock in KK diameters 100-600mm.
Franke LTA & LTB series rotary/indexing tables offer precise positioning, high load capacity & repeatability in a ready to mount compact package.
Franke LDV series ready to mount precision turntable bearings are available in sizes (BPCD) 100, 200, 300, 400, 500, 600,
Franke LDD Slim bearings use ground raceways contained within a steel housing allowing easier fitting as a pre-finished bearing element. The bearing cross sections conforms to international standards & are available from 5.125” to 26” BPCD.
Franke LED bearing elements use ground or profiled round or double profile raceways with plastic cages & retained balls. Special configurations for surface coating options available on request. Sizes from 100mm to 1500mm BPCD are available.
Franke LEG bearing elements use a 2 ring profiled raceway with plastic cage & retained balls The compact design & size allows you to use significantly smaller mounting envelopes than deep groove ball bearing designs & is available from 5mm to 500mm BPCD.
Franke LER bearing elements have unground raceways contained within a rectangular profile & use a retained ballcage, special coatings & cages are available. Standard sizes from 400mm to 1500mm are available. Easy fitting, competitive prices, & short leadtimes apply to this range.
Franke LKB Ball Cages are available from 5mm to 20mm ball diameters as continuous reels up to 50 metres or cut to your required lengths for use in bespoke linear & rotary bearing applications enabling extremely compact & cost effective solutions where standard catalogue products cannot be used. MOST SIZES FROM UK STOCK
